Min. Design Efficiency

Chiparoc, LLC is pleased to offer the following option(s):
7.1/2 H.P. Automatic Recycle System

  •   Reclaimed material is automatically returned to the silo.
  •   7.1/2 H.P. blower system with TEFC motor, coupling, inlet filter, relief valve and check valve.
  •   Collection pod with 3” connections.
  •   15’-0” of 3” hose.
  •   Start / Stop push button control panel.  Included in the central collector controls if central collector is purchased.
  •   3” return line on the silo is the responsibility of the customer.

Automatic Rescue System:

  •   This system utilizes proprietary PLC software to alert the operator of a collection hopper overfill issue and begin running the optional automatic recycle system in an accelerated mode to clear out the overfill.
  •   A panel mounted red light which is activated by the hopper bin indicator.
  •   A panel mounted yellow light indicates the system is running in “Auto Rescue Mode”
  •   The optional recycle system will automatically return to the regular recycle mode 30 minutes after the red light clears.

Rotary Vane Feeder / Upgrade

  •   6” Rotary Vane Feeder with replaceable steel tips in lieu of the 6” butterfly valve listed in the base quote.
  •   Allows for a more consistent and measured discharge rate.
  •   Includes a bolt-on transition mount.
  •   Additional electrical starter located in the control box and required programming.

  Factory mounted and wired.

Dust Collection Shroud / 5’-6” x 8’-6”

  •   Designed for Boost-A-Load type mixer trucks.
  •   Heavy duty construction of 10-gauge plate and channel iron frame.
  •   Complete angle iron hanger system with top mounting brackets and chain.
  •   (2) mounting rings for customers 14” ducting are shipped loose for customer installation.
  •   60” x 1/8” PVC curtain is bolted on all four sides.  Customer is responsible for cutting the entry hole the mixer trucks.
  •   Requires a minimum of 5000 CFM for best performance.
  •   Customer choice of two-part polyurethane paint in grey, white or tan.
  •   Installation is the responsibility of the customer.


Control:

  •  Designed to automatically cycle the filter cleaning pulse.
  •  Self-contained NEMA 4 control panel for the motor starter and disconnect.
  •  Adjustable digital control for air pulse duration and cycle times.
  •  Prewired and tested prior to shipment.
  •  Electrical supply is the responsibility of the customer.

Total Filtration Area Sq./Ft.

15 H.P Direct Drive

1286 Sq. Ft.

CPC - Series Stationary Central Dust Collector

Fan Horsepower

20 H.P Direct Drive

99.99%

(20) 8" X 54"

7600 CFM @ 8"

5600 CFM @ 8"

CPC - 2054

Dust inlets with angle iron mounts

99.99%

325-203-1565          chiparocllc@gmail.com

Number of Cartridges

Cleaning Mechanism

CPC - 2040

(20) 8" X 40"

Reverse Pulse Jet

Chiparoc LLC

325-203-1565          chiparocllc@gmail.com

Normal Air Capacity (CFM)

990 Sq. Ft.

Specifications

Reverse Pulse Jet

(2) 14"

(2) 18"
